GIANT REIGN E+ 2 2022

Trail technology

Proven Maestro rear suspension (160mm) and a powerful but compact SyncDrive Pro motor technology boost your capabilities on steep climbs and rugged descents.

Total control

RideControl Ergo 3 offers integrated, user-friendly button controls that are easy to use. The Giant E-bike App gives you tuning options and E-bike specific fitness tracking.

Long-lasting power

Climb steep mountains and enjoy fun descents all day long with the downtube-integrated EnergyPak

RANGE

How far can I expect to ride on a single battery charge?

The range for a single battery charge can vary greatly depending on conditions such as the combined weight of the rider and cargo; wind resistance; tire pressure and tread profile; terrain and elevation changes; road or trail surface; outdoor temperature; maintenance of the E-Bike; and the condition of the battery.

The bar below gives an approximate range. Conditions are categorized as extreme, good and ideal. Extreme conditions typically occur when riding with a heavy load, strong headwinds or excessive climbs.

ENERGYPAK SMART 625 / SYNCDRIVE PRO

• Extreme: 60 KM
• Good: 120 KM
• Ideal: 190 KM

• Motor: SyncDrive Pro, 85Nm, powered by Yamaha

• Kezelő: RideControl Ergo 3, grip integrated

• Kijelző: RideControl GO, frame integrated LED displayANT+ Wireless display compatible

• Akkumulátor: EnergyPak Smart 625WhEnergyPak Plus range extender compatible

• Méretek: S, M, L, XL

• Szín: Black Diamond

• Váz: ALUXX SL-grade Aluminum, Advanced Forged Composite Upper Rocker, 160mm Maestro suspension system, 'Boost' 148x12mm, UDHTM derrailleur hanger

• Villa: RockShox ZEB Select 29er, 170mm travel, Charger RC damper, 15x110 Boost, Maxle Stealth

• Rugóstag: Fox Float DPX2 Performance, EVOL Large Volume sleeve, 2-position lever, 205x62.5mm Trunnion mount, custom tuned

• Kormány: Giant Contact Trail, 35x800mm

• Grips: Giant Tactal Pro-E, single lock-on

• Stucni: Giant Contact SL 35

• Nyeregcső: Giant Contact Switch, dropper, 30,9mm (S:125, M: 150, L/XL:170)

• Nyereg: Giant Romero Trail

• Pedálok: Flat pedal

• Váltókarok: SRAM NX

• Első váltó: MRP 1X HD2 custom co-molded chain guide

• Hátsó váltó: SRAM GX 12-speed

• Fékek: SRAM Code R, hydraulic disc, 220mm[F] /200mm[R]

• Fékkarok: SRAM Code R

• Fogaskoszorú: SRAM PG-1230, 11-50T, 12-speed

• Lánc: SRAM NX Eagle PowerLock

• Hajtómű: SRAM X-Sync Eagle 36T chainring Praxis e-Cadet+ custom forged crankarm set (S/M:160, L/XL:165)

• Középcsapágy: -

• Felnik: Giant AM 29"[F] 27.5"[R], Tubeless ready, 30mm inner width

• Agyak: Giant eTracker Boost, Sealed cartridge bearing, 6-bolt, , [F] 110x15 [R] 148x12mm Thru-axle

• Küllők: Sapim E-Lite [r] Race [f]

• Külsők: Maxxis Minion DHF 29x2.6" foldable, Tubeless, EXO+, 3C MaxxTerra[F]Maxxis High Roller II 27.5x2.5" foldable, Tubeless, DoubleDown, 3C MaxxTerra Compound [R]

• Kiegészítők: Tubeless kit (liquid, valves, levers, manual, tool)

• Világítás: Optional:- Giant Recon series e-bike lights available and direct connectable
